Using the machine diagram trace the flow of those instructionsthrough the machine. Discuss any changes you feel are needed tomake sure we can properly process this instruction.

• ADIW Rl, k
• CPSE Rd, Rr
• LSR Rd
• ROR Rd
• LD Rd, X
• LD Rd, X+
• LDD Rd, Y+q

stk 2 Inixi 3 de Adrl Lxl pc im rf mux4 dm TYI mux23 Tir @mu x6国 Show transcribed image text stk 2 Inixi 3 de Adrl Lxl pc im rf mux4 dm TYI mux23 Tir @mu x6国
